200 Watt Foldable Solar Panel

200 Watt Foldable Solar Panel
Product Introduction:
Model: PV100
Peak Power(Pm): 100W
Cell type: Monocrystalline silicon
Cell efficiency: Up to 23.4%
Send Inquiry
Description
Technical Parameters
product-718-399
Off-Grid Power Supply

By generating renewable electricity from the sun's energy, 200 watt foldable solar panel is a reliable and budget-friendly power supplier to juice up your laptop, drone, fridge, electric drill, and other devices whether your're at home or on the go.



SOLAR PANELS are compatible with most solar generators on the market.
However, they work best with BLUETTI power stations.
High Conversion Efficiency: Over 23.4% cell efficiency and 95% transparency
Durable & Water-resistant ETFE coating and IP65 Protection
Foldable & Portable: Easy to carry around and set up.

product-720-670



FAQ



Q: Is 200 watt foldable solar panel Waterproof?

A: Yes, IP65 rated for junction box, but do not expose it to constant rain or snow. Yes, IP65 rated for junction box, but do not expose the solar panels to rain or snow. Tips: The charging time are affected by many factors: such as the sunlight intensity and the panel's angle put on the ground. The 200W of solar is tested in an ideal laboratory. However, the intensity of the sunlight constantly changes. In addition, the angel of sunlight to solar panel also changes with the rotation of the sun.

Q: What factors will affect the solar conversation rate?

A: The strength of the sun light B. environment temperature C. the angle you place the solar panel D. the length of the solar cable .

Q: How many pieces of solar panels can be used on a power station?

A: Check the max. open circuit voltage B:the max. short-circuit current C:the max. power of the Portable solar panel D:Make sure the total max. value does not exceed the numbers in the specification when you connect several pieces in series or paralell.





Hot Tags: 200 watt foldable solar panel, China 200 watt foldable solar panel manufacturers, suppliers, factory

Model: PV100 PV200
Peak Power(Pm): 100W 200W
Cell type: Monocrystalline silicon Monocrystalline silicon
Cell efficiency: Up to 23.4% Up to 23.4%
Voltage at max power (Vmp): 20.5V 20.4V
Current at max power (Imp): 4.9A 9.7A
Open circuit voltage(Voc): 24.6V 26.1V
Short circuit current(Isc): 5.8A 10.3A
Dimension(unfolded): 1135*608MM/44.7*23.9inch 590*2265mm/23.2*89.2inch
Dimension(folded): 608*582.5*35MM/23.9*22.9*1.4inch 590*630mm/23.2*24.8inch
Weight: 4.9kg/10.8lbs 7.3kg/16.1lbs
Warranty: 12 Months 12 Months
